Semi Electric Stackers Manufacturer, Distributor, Dealers & Wholesalers

MANUAL SEMI ELECTRIC

Ideal for stacking effortlessly, in tight spaces. Save effort and time. Can do 4-5 times more work than a manual stacker, where lifting is more frequent than moving the goods.

Key Specifications

Model	TMBST 15-30	TMBST 15-35
Capacity	1500 kg	1500 kg
Lifting Height (H)	3000 mm	3500 mm
Fork Length (L)	1150 mm	1150 mm
Fork Width (E)	310-820	310-820
Load Center (C)	400 mm	400 mm
Min turning Radius(R)	1450 mm	1450 mm
Lifting Motor	12/1.5-1.6 V/KW	12/1.5-1.6 V/KW
Overall Length (A)	1700 mm	1700 mm

Model

TMBST 15-30

TMBST 15-35

Capacity

1500 kg

Lifting Height (H)

3000 mm

3500 mm

Fork Length (L)

1150 mm

Fork Width (E)

310-820

Load Center (C)

400 mm

Min turning Radius(R)

1450 mm

Lifting Motor

12/1.5-1.6 V/KW

Overall Length (A)

1700 mm

Features

It has Rubber coated handle. Fully Powder coated body.
Hard chrome plated piston.
Single piece pump.
With Hard Polymer Wheels.

Product Summary

The Semi Electric Stacker (Models: TMBST 15-30 & TMBST 15-35) is designed for efficient stacking in tight spaces, reducing manual effort and saving time. Compared to manual stackers, it can perform 4–5 times more work, making it ideal for operations where frequent lifting is required. Built with a rubber-coated handle and a fully powder-coated body, it ensures durability and operator comfort. The stacker is equipped with a hard chrome-plated piston, a single-piece pump, and hard polymer wheels for smooth and reliable performance.

This stacker comes with a 1500 kg capacity and offers lifting heights of 3000 mm (TMBST 15-30) and 3500 mm (TMBST 15-35). It has a fork length of 1150 mm, adjustable fork width of 310–820 mm, and a load center of 400 mm. With a minimum turning radius of 1450 mm, it operates efficiently even in compact spaces. The lifting motor (1.2/1.5 kW) ensures smooth lifting, with speeds of 0.11 m/s (loaded) and 0.17 m/s (unloaded). Lowering speeds are 0.26 m/s (loaded) and 0.14 m/s (unloaded). Depending on the model, the net weight is 492 kg (15-30) and 515 kg (15-35), and it runs on reliable AMRON/EXIDE batteries.
