| Brand |
hulk |
hulk |
hulk |
hulk |
hulk |
| Model
No
|
HD-F-D3 |
HD-F-D |
HD-F-D5 |
HD-F-D6 |
HD-F-D(Fast) |
| OPENING TIME(Sec) |
3-6 Sec |
3-6 Sec |
3-6 Sec |
3-6 Sec |
1.5Sec |
BOOM
LENGTH(MM) |
3000 MM |
4000 MM |
5000 MM |
6000 MM |
3000 MM |
HEIGHT OF
BOOM FORM
GROUND |
800(MM) |
800(MM) |
800(MM) |
800(MM) |
800(MM) |
CONTROLLER PROTECTING
RATING |
IP55 |
IP55 |
IP55 |
IP55 |
IP55 |
| MOTOR POWER SUPPLY |
230VAC
50HZ |
230VAC
50HZ |
230VAC
50HZ |
230VAC
50HZ |
230VAC
50HZ |
| POWER |
100W |
100W |
100W |
100W |
100W |
STATING
CURRENT |
2.6A |
2.6A |
2.6A |
2.6A |
2.6A |
| TORQUE(Nm) |
400 |
400 |
400 |
400 |
400 |
| DUTYU SE |
INTENSIVE
USE |
INTENSIVE
USE |
INTENSIVE
USE |
INTENSIVE
USE |
INTENSIVE
USE |
OPERATING
TEMP |
-300 C TO
+ 600 C |
-300 C TO
+ 600 C |
-300 C TO
+ 600 C |
-300 C TO
+ 600 C |
-300 C TO
+ 600 C |
DAILY
OPERATING CYCLES
(RECCOMMENDED) |
600 |
600 |
600 |
600 |
600 |
Packing size WXLXH (cm)
Barrier, Boom |
35X106
X27, 12x
300x12 |
35X106
X27, 12x
400x12 |
35X106
X27, 12x
500x12 |
35X106
X27, 12x
600x12 |
35X106
X27, 12x
300x12 |
| Gross weight Barrier, Boom |
60Kg,
12Kg |
60Kg,
15Kg |
60Kg,
15.250Kg |
60Kg,
15.500Kg |
60Kg,
12.500Kg |
|
| |
| Features : |
- Inbuilt micro processor based intelligent controller.
- oller · Electromachnical gear motor with integrated.
- Electronic limit switches, springs for boom counter weight with adjuster.
- Heavy duty steel body with powder coating.
- Colour-golden yelloy.
- Rectangular shaped boom with caps and coverings.
- Manual operation by hand in case of power failure.
|
| |
| |
|
|
|
|
|
