Key Specifications

Model	AS60	AS120	SS40	SS60	SS240
View
Capacity	3 Ton	6 Ton	2 Ton	4 Ton	12 Ton
No. of Load Wheels	6 pcs	8 pcs	4 pcs	8 pcs	16 pcs
Wheel Material	High-strength Nylon (very hard & wear-resistant)
Wheel Size	82×100	115×60	82×100	82×100	115×60
Skate Size (L×W×H mm)	345×270×110	400×345×145	250×310×110	560×395×110	1120×415×145
Net Weight (per skate)	~12 kg	~22 kg	~9 kg	~28 kg	~65 kg
Handle Included	Yes (steering + pull handle)	Yes	Yes	Yes	Yes

Key Features & Benefits

• Extremely high load capacity (2–12 tons per set).
• Super low height (only 110–145 mm) – easily slides under most machines.
• Heavy-duty nylon wheels – no floor damage, no sparks, chemical resistant, very long life.
• 360° rotating top plate with anti-slip rubber pad for safe load placement.
• Powder-coated rugged steel frame – built for years of rough use.
• Connecting rods & alignment bars keep all 4 skates moving in straight line.
• Handles allow one or two persons to pull/push even 10-ton loads easily.
• Works perfectly on concrete, epoxy, or steel floors.

Product Summary

The DR07 Metal Platform Trolley (560 kg) is the go-to choice for daily heavy-duty warehouse and factory use where loads up to half a ton need to be moved regularly. The JK-20/JM-34 Plastic Platform Trucks (175–200 kg) are lightweight, foldable, rust-proof trolleys perfect for offices, supermarkets, hospitals, and homes where space is limited and floors must stay unmarked.

In contrast, the Cargo Trolley Skate Kit series (2–12 tons) belongs to a completely different league — these are specialized machine-moving skates used when you have to shift extremely heavy equipment like CNC machines, transformers, or generators weighing multiple tons. While the first two are everyday push trolleys, the Skate Kit is an industrial-grade solution used occasionally but critically during machine installation, relocation, or maintenance projects.
