The HULK MA-15 is a high-performance mortar spray machine engineered for modern construction needs. It is designed to deliver fast, uniform, and efficient spraying of plaster,
mortar, putty, and various wall coating materials. With its powerful motor and integrated compressor, the MA-15 ensures continuous operation, significantly reducing labor time
and increasing productivity on site.
Key Specifications
| Model |
M311 |
| Power Supply |
4.0 KW |
| Voltage |
220 V |
| Conveying Distance |
15 W |
| Conveying Height |
10 M |
| Air compressor |
3 M3 / HR. |
| Through the particles |
4 MM |
| Weight |
160 Kgs |
| Model |
MA-15 |
| Tank Capacity |
80 L |
| Electric Supply |
400 V / 50 Hz |
| Motor Power |
3 kW |
| Rated |
35 bar |
| Integrated Compressor |
Top 250 |
| Air Flow Rate |
400L/H |
| Compressor Motor Power |
1.1Kw |
| Maximum Pressure |
3 Bar |
| Product Flow Rate |
26 L/min |
| Maximum Grain Size |
5 mm |
| Spraying Distance |
30m X 15m |
| Dimensions (L x W x H) |
140 x 70 x 81 cm |
| Weight |
152 kg |
Features M311
- Power Supply: Equipped with a 4.0 KW motor for high efficiency and reliable performance.
- Voltage: Operates on 220 V, compatible with standard electrical systems.
- Conveying Distance: Capable of spraying mortar up to 15 meters, suitable for medium to large-scale projects.
- Conveying Height: Vertical reach of up to 10 meters, making it effective for multi-storey construction.
- Air Compressor: 3 m³/hr. capacity ensures consistent and powerful spray output.
- Particle Size Handling: Supports mortar particles up to 4 mm, minimizing clogging issues.
- Weight: 160 kg sturdy build with mobility wheels for durability and easy transportation.
- The "HULK" Model 311 is a professional-grade machine that enhances work efficiency, delivers high-quality finishing, and ensures cost-effectiveness for construction projects.
Applications MA-15
- Internal and external wall plastering
- Cement-based mortar spraying
- Gypsum, lime, and ready-mix mortar applications
- Renovation, restoration, and large-scale construction projects
Product Summary
The "HULK" Mortar Spray Machine, Model 311, is a robust and efficient solution designed for plastering, mortar spraying, and surface coating applications. This machine significantly reduces manual labor, ensuring uniform application and enhancing productivity in construction projects. Equipped with a powerful 4.0 kW motor and operating at 220V, it delivers high efficiency and reliable performance, making it an ideal choice for contractors and builders who demand speed, precision, and durability. With a conveying distance of up to 15 meters and a conveying height of up to 10 meters, it is well-suited for medium to large-scale projects, offering effective multi-storey construction coverage.
The HULK MA-15 is a high-performance mortar spray machine engineered for modern construction needs, designed to deliver fast, uniform, and efficient spraying of plaster, mortar, putty, and various wall coating materials. Powered by a 3 kW motor rated at 35 bar and an integrated Top 250 compressor with a 1.1 kW air flow motor, this machine ensures continuous operation, significantly reducing labor time and increasing productivity on site. With an 80L tank capacity and a product flow rate of 26 L/min, it handles a maximum grain size of 5 mm and offers a spraying distance of 30 m horizontally and 15 m vertically. Weighing 152 kg with dimensions of 140 x 70 x 81 cm, it is built for durability and ease of use in demanding environments.
